High‑Precision 3D Hall Magnetic Angle Sensor
Brand: KunTaiXin
Wide Operating Voltage: 1.7V ∼ 3.6V
Wide Temperature Range: -40°C ∼ +125°C
Low Power Consumption: Typical operating current 4‑6 mA
Multiple Interfaces: I²C, SPI, AB quadrature encoder, PWM, analog voltage
Maximum Supported Rotational Speed: 5000 RPM
Maximum Resolution of AB Quadrature Encoder Output: 1024 lines per revolution
Available Packages: SOP‑8L and DFN2×2‑8L
Applications: Absolute‑angle position detection, BLDC motor control, stepper motor control, gimbal motor control, robot joint motors, industrial knobs and control panels, joysticks and game controllers, steering‑angle sensors, valve opening detection, replacement for traditional optical encoders

Low‑Power, High‑Precision 3D Hall‑Effect Sensor IC
Brand: KunTaixin
Typical operating range for X‑Y axes: ±130 mT
Typical operating range for Z‑axis: ±80 mT
Temperature (T) output supported
Absolute position detection capability
Supply voltage: 2.8 V ~ 5.5 V
IO supply voltage down to 1.8 V
AQ2 industrial grade operating temperature: -40 ℃ ~ +105 ℃
AQ3 consumer grade operating temperature: -40 ℃ ~ +85 ℃
Applications:
Agricultural irrigation, knobs & joysticks, linear position detection, 3D position and angle detection, non‑contact magnetic‑field measurement, low‑power magnetic encoders
