High‑Precision 3D Hall Magnetic Angle Sensor
Brand: KunTaiXin
Wide Operating Voltage: 1.7V ∼ 3.6V
Wide Temperature Range: -40°C ∼ +125°C
Low Power Consumption: Typical operating current 4‑6 mA
Multiple Interfaces: I²C, SPI, AB quadrature encoder, PWM, analog voltage
Maximum Supported Rotational Speed: 5000 RPM
Maximum Resolution of AB Quadrature Encoder Output: 1024 lines per revolution
Available Packages: SOP‑8L and DFN2×2‑8L
Applications: Absolute‑angle position detection, BLDC motor control, stepper motor control, gimbal motor control, robot joint motors, industrial knobs and control panels, joysticks and game controllers, steering‑angle sensors, valve opening detection, replacement for traditional optical encoders

Low‑Power, High‑Precision 3D Hall‑Effect Sensor IC
Brand: KunTaixin
Typical operating range for X‑Y axes: ±130 mT
Typical operating range for Z‑axis: ±80 mT
Temperature (T) output supported
Absolute position detection capability
Supply voltage: 2.8 V ~ 5.5 V
IO supply voltage down to 1.8 V
AQ2 industrial grade operating temperature: -40 ℃ ~ +105 ℃
AQ3 consumer grade operating temperature: -40 ℃ ~ +85 ℃
Applications:
Agricultural irrigation, knobs & joysticks, linear position detection, 3D position and angle detection, non‑contact magnetic‑field measurement, low‑power magnetic encoders

High-Precision Absolute Angle Hall Sensor IC
Brand: KunTaiXin
16-bit resolution absolute angle output
High precision with INL error less than ±0.35°
Built-in programmable MTP memory
Magnetic field strength diagnosis and alarm function
Compatible with 3.3 V and 5 V operating voltages
Operating temperature range: -40°C to 105°C
Available in QFN-16L and SOP-8 packages

16-bit High-Precision Low-Latency Hall Angle Encoder IC
Brand: KunTaixin
16-bit resolution absolute angle output
High precision with INL error less than ±0.35°
Suitable for various on-axis and off-axis non-contact applications
Supply voltage compatible with 3.3 V and 5 V
Operating temperature range: -40°C ~ 125°C
Package: QFN-16L

High-Speed High-Precision Magnetic Encoder IC
Brand: KUNTAIXIN
16-bit high-precision absolute angle output
Shaft-mounted application, calibrated INL accuracy < ±0.07°
Built-in MTP programmable memory
Operating voltage: 3.3 V ~ 5 V
Operating temperature: -40 °C ~ 125 °C
Applications
Absolute angle position detection, BLDC motor control, closed-loop stepper motor systems, rail transit platform screen door control

Brand: Kuntai Chip
Wide operating voltage range: 3.0V ~ 5.5V
Low power consumption:
4.5mA at VDD = 3.3V
5.4mA at VDD = 5.0V
High-speed bandwidth up to 30kHz
Package Types: SOT23, TO-92S, DFN1616
Operating temperature range: -40℃ ~ 125℃

GaAs Hall Element (Matrix Brand)
Brand: Matrix
Operating Temperature Range: -40℃ ~ 125℃
Storage Temperature Range: -40℃ ~ 150℃
Maximum Input Current: 13 mA
Thin Profile
Similar Sensitivity
Similar Offset Voltage
Similar Temperature Stability
High Offset Voltage Stability

Hall Element
Brand: Nissela
Voltage: 196-428mV
Maximum Current: 20mA
Operating Temperature: -40~+110°C
Applications: Brushless Motors, Position/Rotation Sensors, Current Sensors, Magnetic Field Strength Meters, Magnetic Card Identification Modules, Non-Contact Switches, etc.

Bipolar Latch Hall Effect IC
Brand: Wangjiu
Voltage (V): 2.5V - 18V
Maximum current (A): 25mA
Operating temperature (°C): -40~+125
Package: SOT23/TO - 92
Applications: Brushless Direct Current (BLDC) motors, VCD/DVD loaders, CD/DVD ROMs, detectors, speed measuring devices, household appliances, home security systems

Gallium Arsenide Hall Element
Brand: Juzhen (Matrix)
Maximum Input Current: 14mA
Operating Temperature: -40~+125°C
Input Resistance: 1250Ω
Overall Dimension: 2.51.50.6 (unit not specified, typically mm for such components)
Sensitivity: ~90mV @ 5mA @ 50mT
Package: SSOT-4
Applications: Displacement monitoring (consumer electronics), displacement sensors (camera modules)

微功耗全极性霍尔开关
品牌：乐业达
工作电压：1.65V ~ 5.5
工作温度：-40℃～150℃
封装：SOT-23-3L 、TO-92S、DFN-4L
输出方式：开漏输出、CMOS 输出
应用：家用电器、工业三表、触屏手机、平板电脑、笔记本电脑、数码相机、玩具、游戏机等
